Roof Systems Panel Rib Roof

Panel Rib™ Roof System is a high-quality roofing solution with the following features and benefits:

Features:

  • Standard Thickness: The Panel Rib™ Roof is available in 26 gauge standard thickness, with optional 24 and 22 gauge.
  • 36″ Coverage with High Ribs: It offers a 36″ coverage with 1 3/16″ high ribs spaced 12″ on center, providing structural strength and rigidity.
  • Low Roof Slopes: The system can accommodate roof slopes as low as 1/2″:12″, allowing flexibility in design.
  • Long Lengths: Panel Rib™ Roof panels can be manufactured in lengths up to 48′, reducing the number of seams and enhancing the overall appearance.
  • Stainless Steel Capped Fasteners: The panels are installed using self-drilling stainless steel capped fasteners, ensuring secure attachment.
  • Galvalume® and Color Options: The roof panels are available in clear-coated Galvalume® as well as a variety of color options with KXL finish. The KXL finish provides enhanced durability and comes with a 25-year material warranty.
  • Wind Uplift Ratings: The system has UL 60 and UL 90 wind uplift ratings available, indicating its ability to withstand high winds.
  • Product Approval: The Panel Rib™ Roof System is approved for use in Florida and Miami-Dade County.
  • Purlin Bearing Edge: The system features a purlin bearing edge, which improves weathertightness and simplifies installation.
  • Economical and Reliable: This roof system offers an economical solution without compromising performance, providing years of reliable service.

Benefits:

  • Attractive Appearance: The Panel Rib™ Roof System offers a clean, appealing aesthetic that enhances the overall look of the building.
  • Energy Efficiency: The system offers enhanced energy efficiency with cool color choices, helping to reduce energy consumption and lower cooling costs.
  • Industry Certification: The system meets the highest standards for certification in the industry, ensuring its quality and performance.

Overall, Panel Rib™ Roof System combines durability, aesthetics, energy efficiency, and ease of installation, making it a reliable and cost-effective roofing solution for a wide range of applications.

The Panel Rib Roof panels offered are available in standard 26 gauge thickness, with an optional 24 gauge. These panels have a width of 36″ and feature 1-3/16″ high ribs. They can be produced in lengths of up to 48′, providing flexibility in design and reducing the number of seams.

The panels are designed with a purlin bearing edge (PBE), which enhances strength and rigidity. They are attached using self-drilling, stainless steel capped fasteners that match the color of the panels, ensuring a secure and aesthetically pleasing installation. The absence of field seaming speeds up the installation process, and the wide module and long length of the panels minimize sidelaps and endlaps, further increasing installation efficiency.

To ensure weather resistance, sealant is applied to every metal-to-metal contact point. The roof slope can be as low as ½:12″, allowing for design flexibility. Additionally, the Panel Rib Roof can accommodate up to 6″ of fiberglass blanket insulation, providing high levels of energy efficiency.

The Panel Rib Roof panels are available in a variety of color options with a KXL finish, which is a durable coating that maintains its appearance over time. We also offers unpainted Galvalume® panels.

Overall, the Panel Rib Roof system combines economy and durability, providing a reliable roofing solution that is easy to install, weather-resistant, and energy-efficient.
