The Panel Rib wall system is a versatile and economical solution for various building applications. Here are the key features and benefits of the Panel Rib wall system:
- Panel dimensions: The Panel Rib wall panel offers 36″ coverage with 1-3/16″ high ribs spaced 12″ on center. This ribbed profile adds visual interest and creates depth on the wall surface.
- Gauge options: The Panel Rib is available in 24 and 26 gauge thicknesses, providing flexibility to meet different codes and specifications.
- Color options and finishes: The Panel Rib wall panel comes in a variety of color options with the KXL finish. The KXL paint system is a PVDF finish applied to the steel, offering a long-lasting color that resists fading and chalking. The paint finish is backed by a 25-year warranty.
- Fastener installation: The wall panels are installed with self-drilling stainless steel capped fasteners, ensuring secure attachment and efficient installation.
- Length options: Panel Rib panels are available in lengths up to 48′, allowing for longer panel spans and minimizing the need for end laps. This enhances the overall wall integrity and reduces potential leakage points.
- Compliance: The Panel Rib wall system is approved for use in Florida and Miami-Dade County, meeting rigorous building code requirements in those areas.
- Durability and maintenance: Engineered for durability, the Panel Rib wall panels are designed to withstand the elements and reduce maintenance costs over time. The superior paint finishes help maintain the panel’s appearance and minimize maintenance efforts.
- Crimped base option: The Panel Rib wall system offers a crimped base option, eliminating the need for separate base trim. This not only accelerates installation but also provides a clean and finished look to the wall system.
- Versatility and affordability: The Panel Rib wall system is an economical choice suitable for a wide range of building applications. Its versatility, durability, and aesthetic appeal make it a popular option for various projects.
The Panel Rib wall system offers an economical and durable solution for building exteriors, providing an attractive appearance, ease of installation, and long-term performance.
The Panel Rib wall system is known for its affordability and offers several advantages over wood, concrete, or masonry alternatives. Here are the key features and benefits of the Panel Rib wall system:
- Economical choice: The Panel Rib wall system is a cost-effective solution compared to traditional wood, concrete, or masonry options.
- Continuous panel coverage: With lengths available up to 48′, the Panel Rib panels can provide continuous coverage from foundation to eave. This eliminates the need for end laps and ensures wall integrity and weather-tightness.
- Self-drilling fasteners: The panels are attached using self-drilling, stainless steel capped color-matched fasteners. This type of fastening system ensures secure attachment and simplifies the installation process.
- Crimped base option: VP offers an exclusive crimped base Panel Rib option. This eliminates the need for notched metal or rubber closures and painted base trim, saving installation time and material costs. The crimped base also reduces access for pests, enhancing the building’s security.
- Insulation compatibility: The Panel Rib wall system can effectively accommodate blanket insulation as well as up to 2-1/2″ of rigid board insulation. This allows for enhanced thermal efficiency and energy savings. Your VP Builder can assist in selecting the optimal insulation approach based on upfront costs and long-term energy considerations.
- Wide color selection: Panel Rib panels are available in a wide selection of standard colors with KXL finishes. The KXL paint system is a PVDF finish applied to the zinc aluminum coated steel, providing long-lasting color durability and resistance to fading and chalking.
In summary, the Panel Rib wall system offers an economical exterior wall solution that provides continuous panel coverage, simplified installation, insulation flexibility, and a variety of color options. It is a cost-effective and durable choice for building owners looking for an affordable and reliable wall system.
